ISO III / JIS II DUAL Write Heads


ISO III / JIS II track writer.
Writer for magnetic cards.
Bank passbook and other auto card system terminals.
Customized head assembling : Magnetic head and spring.
Other custom electric specifications are available in this series.

| PICTURES

PRODUCT IMAGE DIMENSIONS(mm)
JIS-MI-W ms_JIS2-RW

| SPECIFICATIONS

ITEMS CONDITIONS MODELS
YIO-612205
Inductance 1 KHz I-W 0.9 mH ±30%
J-W 0.7 mH ±30%
D.C resistance I-W 3.5 Ω ±25%
J-W 4.5 Ω ±25%
Core track width I-W 3.0 mm
J-W 6.0 mm
Sendust cores Standard min. 1,000 k
Insuation resistance 10 ㏁ min.
Size 14.0×12.4×15.0 mm
